उत्पाद विवरण:
|
| भाग संख्या: | एडीएम2484ईबीआरडब्ल्यूजेड | वोल्टेज - अलगाव: | 5000Vrms |
|---|---|---|---|
| आधार - सामग्री दर: | 500kbps | सामान्य मोड क्षणिक प्रतिरक्षा (न्यूनतम): | 25kV/μs |
| वोल्टेज - आपूर्ति: | 3.3 वी, 5 वी | परिचालन तापमान: | -40 ° C ~ 85 ° C |
ADM2484EBRWZ is an isolated data transceiver with ±15 kV ESD protection suitable for high speed, half- or full-duplex communication on multipoint transmission lines. For half-duplex operation, the transmitter outputs and receiver inputs share the same transmission line. Transmitter Output Pin Y links externally to Receiver Input Pin A, and Transmitter Output Pin Z links externally to Receiver Input Pin B.
| Product Category: | Digital Isolators |
|---|---|
| Mounting Style: | SMD/SMT |
| Package / Case: | SOIC-16 |
| Number of Channels: | 3 Channel |
| Polarity: | Unidirectional |
| Data Rate: | 500 kb/s |
| Isolation Voltage: | 5000 Vrms |
| Isolation Type: | Galvanic Isolation |
| Supply Voltage - Max: | 5.5 V |
| Supply Voltage - Min: | 3 V |
| Operating Supply Current: | 2 mA |
| Propagation Delay Time: | 700 ns |
| Minimum Operating Temperature: | -40℃ |
| Maximum Operating Temperature: | +85℃ |
| Duplex: | Half/Full Duplex |
| Forward Channels: | 2 Channel |
| Maximum Fall Time: | 1.1 us |
| Maximum Rise Time: | 1.1 us |
| Product Type: | Digital Isolators |
| Protocol Supported: | RS-485, RS-422 |
