उत्पाद विवरण:
|
| भाग संख्या: | HCNW3120-500E | वोल्टेज - अलगाव: | 5000Vrms |
|---|---|---|---|
| सामान्य मोड क्षणिक प्रतिरक्षण (न्यूनतम): | 25kV/μs | प्रसार विलंब tpLH / tpHL (अधिकतम): | 500एनएस, 500एनएस |
| पल्स चौड़ाई विरूपण (अधिकतम): | 300ns | वृद्धि / गिरना समय (टाइप): | 100एनएस, 100एनएस |
HCNW3120-500E contains a GaAsP LED while the HCPL-J312 and the HCNW3120-500E contain an AIGaAs LED. The LED is optically coupled to an integrated circuit with a power output stage. These optocouplers are ideally suited for driving power IGBTs and MOSFETs used in motor control inverter applications.
The high operating voltage range of the output stage provides the drive voltages required by gate controlled devices. The voltage and current supplied by these optocouplers make them ideally suited for directly driving IGBTs with ratings up to 1200V/100A. For IGBTs with higher ratings, the HCPL-3120 series can be used to drive a discrete power stage, which drives the IGBT gate.
| Parameter | Value |
|---|---|
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 25kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 500ns, 500ns |
| Pulse Width Distortion (Max) | 300ns |
| Rise / Fall Time (Typ) | 100ns, 100ns |
| Current - Output High, Low | 2A, 2A |
| Current - Peak Output | 2.5A |
| Voltage - Forward (Vf) (Typ) | 1.6V |
| Current - DC Forward (If) (Max) | 25 mA |
| Voltage - Output Supply | 15V ~ 30V |
| Operating Temperature | -40°C ~ 100°C |
