उत्पाद विवरण:
|
| Part Number: | MAX6753KA29 | Voltage - Threshold: | 2.925V |
|---|---|---|---|
| Reset Timeout: | 5.692ms Minimum | Reset: | Active Low |
| Operating Temperature: | -40°C ~ 125°C (TA) | Supply Voltage - Max:: | 5.5 V |
MAX6753KA29 Integrated Circuit Chip µP Reset Circuits with Capacitor-Adjustable Reset/Watchdog Timeout Delay
Product Description Of MAX6753KA29
MAX6753KA29 low-power microprocessor (µP) supervisory circuits monitor single/dual system supply voltages from 1.575V to 5V and provide maximum adjustability for reset and watchdog functions. These devices assert a reset signal whenever the VCC supply voltage or RESET IN falls below its reset threshold or when manual reset is pulled low. The reset output remains asserted for the reset timeout period after VCC and RESET IN rise above the reset threshold. The reset function features immunity to power-supply transients.
Specification Of MAX6753KA29
|
|
2.925 V |
|
|
1 Input |
|
|
7.59 ms |
|
|
5.5 V |
|
|
- 40 C |
|
|
+ 125 C |
|
|
2 % |
|
Height: |
1.1 mm |
|
Operating Supply Current: |
5 uA |
|
Pd - Power Dissipation: |
714 mW |
|
Supply Voltage - Min: |
1 V |
|
Width: |
1.63 mm |
|
Unit Weight: |
40 mg |
Features Of MAX6753KA29
Configurable Reset and Watchdog Options EnablesWide Variety of Applications
Factory-Set Reset Threshold Options from 1.575V to 5V in ～ 100mV Increments
Adjustable Reset Threshold Options
Single/Dual Voltage Monitoring
Capacitor-Adjustable Reset Timeout
Capacitor-Adjustable Watchdog Timeout
Min/Max (Windowed) Watchdog Option
Manual-Reset Input Option
Push-Pull or Open-Drain Active-Low RESET Output Options
3.7µA Supply Current Reduces System Power Consumption
Integrated Power Supply Protection Increases Robustness
Power-Supply Transient Immunity
Guaranteed Active-Low RESET Valid for VCC ≥ 1V
8-Pin SOT23 Packages Saves Board Space
AEC-Q100 Qualified. Refer to Ordering Information for Specific /V Trim Variants
Applications Of MAX6753KA29
Automotive
Battery-Powered Computers/Controllers
Computers
Critical µP Monitoring
Embedded Controllers
Intelligent Instruments
Medical Equipment
Portable Equipment
Set-Top Boxes
